OWON XDG3102 2CH 100MHz 1.25GSa/s 14 bits Touch Screen Arbitrary Waveform Generator
4.3 (47 items)
Limited Time SaleUS$479.40 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211160414 | Release Date | 2026/04/04 | List Price | US$319.60 | Model Number | 211160414 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
XDG3102,100MHz Touch Screen Arbitrary Waveform Generator 8" 800*600 pixels touch screen LCD 80MHz frequency output with dual channel 1.25GS/s sampling rate and 1μHz frequency resolution 1M arbitrary waveform length and 14 bits vertical resolution Comprehensive waveform output: 6 group basic waveforms and 152 group built-in arbitrary waveforms Comprehensive modulation options: AM, FM, PM, FSK, 3FSK, 4FSK, PSK, OSK, ASK, BPSK, PWM, sweep and burst 100mHz to 200MHz frequency counter integrated Supported SCPI and LabVIEW Standard Waveformsine, square, pulse, ramp, noise, and harmonic Arbitrary Waveformexponential rise, exponential fall, sin(x)/x, step wave, and others, total 150 built-in waveforms, and user-defined arbitrary waveform Sine1μHz - 100MHz Square1μHz - 30MHz Pulse1μHz - 25MHz Ramp1μHz - 5MHz Harmonic 1μHz - 40MHz Noise120MHz (-3dB, typical) Arbitrary Waveform built-in waveform: 1uHz - 15MHz user-defined waveform: 1uHz - 50MHz Accuracy ±1ppm, 0°C - 40°C Amplitude into 50Ω load1mVpp - 10Vpp (≤40MHz); 1mVpp - 5Vpp (≤80MHz) 1mVpp - 2.5Vpp (≤120MHz); 1mVpp - 1Vpp (≤250MHz) into open circuit or high-Z2mVpp - 20Vpp (≤40MHz); 2mVpp - 10Vpp (≤80MHz); 2mVpp - 5Vpp (≤120MHz); 2mVpp - 2Vpp (≤250MHz) Frequency Counter Functionfrequency period, +width, -width, +duty, and -duty Frequency Range100mHz - 200MHz Frequency Resolution 7 digits Input / Output Typefrequency counter, external modulation input, external trigger input, external reference clock input / output Communication InterfaceUSB Host, USB Device, and LAN Dimension (W×H×D)340 x 177 x 90 (mm) Weight (without package)2.50kg What's in the package: Power Cord CD Rom Quick Guide USB Cable Q9 Cable
- 8 inch 800*600 pixels touch screen LCD 100MHz frequency output with dual channel
- 1.25GS/s sampling rate and 1μHz frequency resolution 1M arbitrary waveform length and 14 bits vertical resolution
- Comprehensive waveform output : 6 group basic waveforms and 152 group built-in arbitrary waveforms Comprehensive modulation options: AM, FM, PM, FSK, 3FSK, 4FSK, PSK, OSK, ASK, BPSK, PWM, sweep and burst
- 100mHz to 200MHz frequency counter integrated Supported SCPI and LabVIEW
| Material | Aluminum |
|---|---|
| Manufacturer | LILLIPUT |
| Batteries Included | No |
| Batteries Required | No |
| Is Discontinued By Manufacturer | No |
