Teltonika TSW200000010 Model TSW200 Industrial Unmanaged POE+ Switch, 8X PoE Ports, 8 x Ethernet Ports, Rugged Aluminum Housing, 2 SFP Ports for Long-Range Fiber-Optic, 20 Gbps Bandwidth Non-Blocking

Teltonika TSW200000010 Model TSW200 Industrial Unmanaged POE+ Switch, 8x PoE Ports, 8 x Ethernet Ports, Rugged Aluminum Housing, 2 SFP Ports For Long-Range Fiber-Optic, 20 Gbps Bandwidth Non-blocking TSW200 is industrial unmanaged switch from Teltonika Networks. TSW200 is equipped with 2 SFP ports for long-range Fiber-optic communication and 8 Ethernet ports which support IEEE802.3af and IEE802.3at Power-over-Ethernet standards Key Features: - 8 x LAN ports, 2 x SFP ports - Rugged aluminum housing - IP30 ingress protection rating - Up to 20 Gbps (non-blocking) - Package includes: TSW200, QSG (Quick Start Guide) (NO POWER SUPPLY INCLUDED) Specifications: Ethernet: - LAN: 8 x LAN ports, 10/100/1000 Mbps - Fiber: 2 x SFP ports PoE: - PoE ports: 1 - 8 - PoE Max Power per Port (at PSE): 30 W - Total PoE Power Budget (at PSE): 240W Performance Specifications: - Bandwidth (Non-blocking): 20 Gbps - Packet buffer: 128 KB - MAC address table size: 2k entries Power: - Connector: 2 pin industrial DC power socket - Input voltage range: 7-57 VDC - Input voltage range for PoE: 44-57 VDC - Power consumption (idle/max no PoE/max): <2.2 W/<19 W/106 W Physical Interfaces (Ports, LEDs): - Ethernet: 8 x RJ45 ports, 10/100/1000 Mbps - Fiber: 2 x SFP ports - Status LEDs: 1 x Power LED, 16 x LAN status LED’s 2 x SFP status LEDs - Power: 1 x 2 pin industrial DC power socket - Ground: 1 x Grounding screw Physical Specification: - Casing material: Full aluminum housing - Dimensions (W x H x D): 5.19 x 1.74 x 3.74 inches - Weight: 1.1 pounds

• 8 x LAN ports, 2 x SFP ports
• Rugged aluminum housing
• IP30 ingress protection rating
• Up to 20 Gbps (non-blocking)
• Package includes: TSW200, QSG (Quick Start Guide) (NO POWER SUPPLY INCLUDED)
